High current dual purpose 30A 12V DC to DC battery charger
Suitable for deep cycle and cranking lead acid batteries of 70Ah and higher battery capacities
Eliminates dual battery switch
Will not flatten vehicle battery
Compensates for voltage drops over supply wires
Dual purpose lead acid battery charger (charges from car or solar panel without having to re-connect car or solar panel)
Integrated 360W MPPC solar charger
Integrated alternator overload protection
Integrated bypass circuit automatically connects loads directly to alternator when charger operates thus making full 30A available to charge battery.
Three state charger optimises charging (bulk, constant voltage and trickle charging)
Two colour charge indicator LED shows charging and charge completion status
Integrated battery temperature compensation to prolong battery life
Twin two speed thermally controlled cooling fans
Integrated over temperature protection
Short circuit and reverse battery protection on all inputs and outputs
Sturdy powder coated mild steel enclosure
Easy installation with high quality screw type wire connections
Warning
Our DCDC30A charger is a serious machine that can draw up to 50A from your vehicle's alternator. In order to protect your alternator we have included a feature that reduces the charging current progressively if the input voltage from the alternator drops and approaches 13V. It is therefore necessary to use wire sizes as specified to prevent charge current reduction as a result of voltage drops over supply wires.
Technical Notes
Switch ON voltage
:
>13,3V (on ignition input)
Switch OFF voltage
:
<12.5V (on ignition input)
Charge input voltage
:
10.5V to 15V between GND and +Car input
Solar input power
:
360W max
Charge current
:
30A max
Output voltage
:
14.2+/-0.1V in charge mode (Amber LED ON)
Output voltage
:
13.8 +/-0.1V in Trickle mode (Green LED ON)
Load current
:
25A max
Input current
:
65A max with max load current of 25A
Operating temperature
:
-10 to +45 degrees Celsius
Dimensions
:
175mm x 165mm x 68mm
Weight
:
1425 gram
